New GOLDFREN Brake Pad - S3 Sintered Sports (PBPH246) #GF137S3

GOLDfren began manufacturing sintered disc brake pads for a wide range of off-road and road motorcycles in 1991, nearly three decades on from their first motorcycle brake pads GOLDfren has become one of the largest aftermarket manufacturers in the motorcycle brake disc pad industry. Their development of next-generation products has kept them at the technological forefront of Sintered Friction Braking providing you with confidence in the performance, durability and reliability of your brakes.

S3 Series:

The S3 sintered compound is optimal in dry and wet conditions for road & off-road motorcycles. For the road application, S3 pads are suitable for both the front and rear brake while on off-road applications the S3 is only recommended for the front brake. The S3 series is designed for low abrasive interaction with the rotor and quieter braking due to the ceramic composite material. It has an HH friction rating and performs better at higher temperatures than the AD compound. Friction materials contain metal-ceramic with a bronze-graphite and non-metallic friction additives are spread evenly on the base fine bronze body to achieve optimal friction properties.

Features:

• Very high static friction coefficient
• Minimal difference between wet and dry braking performance
• Good abrasive resistance
• Low abrasive interaction with the brake rotor material
• Longer life compared to organic and Kevlar composite materials

Application:

• For riders who demand a bit more than average from their bikes
• Recommended on both front and rear brakes (road application)
• Can also be used on the front brakes of off-road bikes and ATVs
• Works well on both dry and wet conditions

Operating Parameters:

• Specific pressure: 3.0 Mpa
• Sliding speed: 45 m/s
• Constant maximum temp: 450°C
• Short time maximum temp: 800°C
• Counter-surfaces: steel disks

What is a sintered brake pad?

GOLDfren only manufacturers sintered brake pads that contain metal-ceramic and ceramic-carbon friction materials, these materials allow for less brake dust and a quieter braking experience. Sintered brake pads are made by fusing together metallic particles under high temperature and pressure which enhances friction properties and pad life, resulting in longer life and stronger braking. Sintered brake pads experience no brake fade when operating at high temperatures and in wet conditions. They also last up to 5 times longer than organic pads and provide additional braking strength. All materials used are environmentally friendly and do not contain any lead, asbestos, fibreglass or formaldehyde.

Reminder: one set of brake pads services one brake disc, if you are servicing multiple discs you will need multiple sets of brake pads.

Make	Model	Year Range	Capacity
Gilera	50 RUNNER	2002-2004	50
Gilera	FXR180 RUNNER SP GRIMECA	1999-2002	180
Gilera	RC500 FOUCO IE	2007-2010	500
Piaggio	BEVERLY 350	2015-2020	350
Piaggio	MP3 300	2013-2013	300
Piaggio	ZIP 100 (4 stroke)	2006-2011	50
Piaggio	ZIP 50 (2 stroke)	2006-2020	50
Piaggio/Vespa	100 ZIP	2006-2006	100
Piaggio/Vespa	300 MP3 LT	2010-2010	300
Piaggio/Vespa	50 ZIP II 4T	2000-2000	50
Piaggio/Vespa	ET2 50	1997-2001	50
Piaggio/Vespa	ET2 50 2T, AC, EURO 2	2002-2002	50
Piaggio/Vespa	ET4 125	1996-2000	125
Piaggio/Vespa	LE 125 LIBERTY	1999-2001	125
Piaggio/Vespa	LE 125 LIBERTY, 4T	2002-2008	125
Piaggio/Vespa	LX 125 4 T	2005-2006	125
Piaggio/Vespa	LX 125 4 T E.I. 3V	2011-2013	125
Piaggio/Vespa	LX 125 EURO 3 4 T	2006-2008	125
Piaggio/Vespa	LX 150	2005-2009	150
Piaggio/Vespa	LX 50 2T/4T	2005-2005	50
Piaggio/Vespa	LX50 2T	2011-2012	50
Piaggio/Vespa	MP3 500	2010-2010	500
Piaggio/Vespa	S 50 2T	2007-2012	50
Vespa	ET2 50 (2 stroke)	2006-2006	50
Vespa	ET4 150 (4 stroke)	2006-2006	150
Vespa	LX 50	2007-2015	50



FA260 | FDB2056 | 43105 ARB 000A | 494938 | 498846 | 647073 | 647157 | 647170 | 651356 | PE 756676 | PE 757243 | PE 802219 | GF137-S3 | 724
